JCMMZ32 Rod side external thread standard cylinder
Browse:
1. Add foot type and flange type [New]
2. The overall length is shortened to a maximum of 97mm
3. The maximum weight reduction is 54% (0.69kg→0.32kg)
4. A variety of end cap shapes can be selected
6. Optional rod end and rod end thread types
7. With magnetic switch (JCDM series: JCDM)
2. The overall length is shortened to a maximum of 97mm
3. The maximum weight reduction is 54% (0.69kg→0.32kg)
4. A variety of end cap shapes can be selected
6. Optional rod end and rod end thread types
7. With magnetic switch (JCDM series: JCDM)
Click the order code to learn more about each product！ Download: SMC cylinder JCM, JCDMBZ, JCDMB, JCDMM, JCDMMZ overall dimensions sample parameter selection manual
| Order code | Attributes | Sale price (excluding tax) | Sale price (including tax) | Quantity | |
|---|---|---|---|---|---|
| 1587298 | JCMMZ32TN-25F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $26.91 Current Valid Price | $30.41 | |
| 1587299 | JCMMZ32TN-25 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $26.91 Current Valid Price | $30.41 | |
| 1587300 | JCMMZ32TN-50F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $28.29 Current Valid Price | $31.97 | |
| 1587301 | JCMMZ32TN-50 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $28.29 Current Valid Price | $31.97 | |
| 1587302 | JCMMZ32TN-75F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $29.66 Current Valid Price | $33.52 | |
| 1587303 | JCMMZ32TN-75 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $29.66 Current Valid Price | $33.52 | |
| 1587304 | JCMMZ32TN-100 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $31.20 Current Valid Price | $35.26 | |
| 1587305 | JCMMZ32TN-100F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $31.20 Current Valid Price | $35.26 | |
| 1587306 | JCMMZ32TN-125 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $32.57 Current Valid Price | $36.8 | |
| 1587307 | JCMMZ32TN-125F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $32.57 Current Valid Price | $36.8 | |
| 1587308 | JCMMZ32TN-150F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $33.94 Current Valid Price | $38.35 | |
| 1587309 | JCMMZ32TN-150 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $33.94 Current Valid Price | $38.35 | |
| 1587310 | JCMMZ32TN-200 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $36.86 Current Valid Price | $41.65 | |
| 1587311 | JCMMZ32TN-200F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $36.86 Current Valid Price | $41.65 | |
| 1587312 | JCMMZ32TN-250 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $39.77 Current Valid Price | $44.94 | |
| 1587313 | JCMMZ32TN-250F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $39.77 Current Valid Price | $44.94 | |
| 1587314 | JCMMZ32TN-300F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $42.51 Current Valid Price | $48.04 | |
| 1587315 | JCMMZ32TN-300 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $42.51 Current Valid Price | $48.04 | |
| 1587316 | JCMMZ32-25 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $26.91 Current Valid Price | $30.41 | |
| 1587317 | JCMMZ32-25F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $26.91 Current Valid Price | $30.41 | |
| 1587318 | JCMMZ32-25D | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $27.77 Current Valid Price | $31.38 | |
| 1587319 | JCMMZ32-50 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $28.29 Current Valid Price | $31.97 | |
| 1587320 | JCMMZ32-50F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $28.29 Current Valid Price | $31.97 | |
| 1587321 | JCMMZ32-40D | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $29.14 Current Valid Price | $32.93 | |
| 1587322 | JCMMZ32-75 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $29.66 Current Valid Price | $33.52 | |
| 1587323 | JCMMZ32-75F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $29.66 Current Valid Price | $33.52 | |
| 1587324 | JCMMZ32-100F | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $31.20 Current Valid Price | $35.26 | |
| 1587325 | JCMMZ32-100 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $31.20 Current Valid Price | $35.26 | |
| 1587326 | JCMMZ32-100D | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $32.06 Current Valid Price | $36.23 | |
| 1587327 | JCMMZ32-125 | Maximum operating pressure:0.7Mpa Minimum operating pressure:0.05Mpa Ambient temperature:-5℃-60℃ | $32.57 Current Valid Price | $36.8 | |
