CDM2D20 Double earring type mini cylinder
Browse:
1. Standardization of internal threads at rod ends
2. The operability of the magnetic switch is improved and the position is easy to adjust.
3. Equipped with single earring type and trunnion type swing base
4. The models of rod end mounting parts and swing base mounting parts are set (saving time of ordering cylinders and mounting parts separately)
5. With magnetic switch (CDM2-Z series: CDM2, CDM2W, CDM2K, CDM2KW, CDM2R, CDM2RK, CDM2□P, CDBM2)
2. The operability of the magnetic switch is improved and the position is easy to adjust.
3. Equipped with single earring type and trunnion type swing base
4. The models of rod end mounting parts and swing base mounting parts are set (saving time of ordering cylinders and mounting parts separately)
5. With magnetic switch (CDM2-Z series: CDM2, CDM2W, CDM2K, CDM2KW, CDM2R, CDM2RK, CDM2□P, CDBM2)
Click the order code to learn more about each product！ Download: SMC standard cylinder CDM2B, CDM2L, CDM2F, CDM2G, CDM2C, CDM2D, CDM2U, CDM2T, CDM2E, CDM2V, CDM2BZ, CDM2FZ, CDM2UZ data parameter selection manual
| Order code | Attributes | Sale price (excluding tax) | Sale price (including tax) | Quantity | |
|---|---|---|---|---|---|
| 811037 | CDM2D20-310-C73 | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $72.51 Current Valid Price | $81.94 | |
| 811038 | CDM2D20M-25Z | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $33.77 Current Valid Price | $38.16 | |
| 811039 | CDM2D20M-35Z-W | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $39.43 Current Valid Price | $44.56 | |
| 811040 | CDM2D20M-75Z-C73 | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $61.71 Current Valid Price | $69.73 | |
| 811041 | CDM2D20M-100Z-M9NW | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $72.86 Current Valid Price | $82.33 | |
| 811042 | CDM2D20M-100Z-M9BAZ | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $88.29 Current Valid Price | $99.77 | |
| 811043 | CDM2D20F-25-M9N | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $66.51 Current Valid Price | $75.16 | |
| 811044 | CDM2D20F-50A-M9PWL | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $81.94 Current Valid Price | $92.59 | |
| 811045 | CDM2D20F-450-C73 | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $82.80 Current Valid Price | $93.56 | |
| 811046 | CDM2D20F-125S-M9NL | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $90.34 Current Valid Price | $102.08 | |
| 811047 | CDM2D20R-25Z | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $39.94 Current Valid Price | $45.13 | |
| 811048 | CDM2D20R-20Z | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $39.94 Current Valid Price | $45.13 | |
| 811049 | CDM2D20R-10Z | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $39.94 Current Valid Price | $45.13 | |
| 811050 | CDM2D20R-50Z | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $41.49 Current Valid Price | $46.88 | |
| 811051 | CDM2D20R-45Z | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $41.49 Current Valid Price | $46.88 | |
| 811052 | CDM2D20R-100Z | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $44.23 Current Valid Price | $49.98 | |
| 811053 | CDM2D20R-25AZ | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $48.86 Current Valid Price | $55.21 | |
| 811054 | CDM2D20R-25AZ-XC6 | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $49.37 Current Valid Price | $55.79 | |
| 811055 | CDM2D20R-90AZ | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $53.14 Current Valid Price | $60.05 | |
| 811056 | CDM2D20R-125AZ | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $54.51 Current Valid Price | $61.6 | |
| 811057 | CDM2D20R-15Z-M9BAL-XC6 | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $87.43 Current Valid Price | $98.8 | |
| 811058 | CDM2D20R-40Z-M9BAL | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $88.29 Current Valid Price | $99.77 | |
| 811059 | CDM2D20R-45Z-M9BAL-XC6 | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $88.80 Current Valid Price | $100.34 | |
| 811060 | CDM2D20R-40Z-M9BAZ | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $91.71 Current Valid Price | $103.63 | |
| 811061 | CDM2D20R-50Z-W-M9BAL-XC6 | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $93.09 Current Valid Price | $105.19 | |
| 811062 | CDM2D20R-200Z-M9BA-XC6 | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $93.94 Current Valid Price | $106.15 | |
| 811063 | CDM2D20R-25AZ-M9BAL | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $95.66 Current Valid Price | $108.1 | |
| 811064 | CDM2D20R-50AZ-M9BAL | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $97.20 Current Valid Price | $109.84 | |
| 811065 | CDM2D20R-30AZ-M9BAL-XC6 | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $97.71 Current Valid Price | $110.41 | |
| 811066 | CDM2D20R-25Z-H7BAL | Piping diameter:1/8 Rod end thread size:M8X1.25 Minimum operating pressure:0.05 MPa | $98.23 Current Valid Price | $111 | |
